Facilities
Engineering Manufacturing Facilities
List of Machinery
| Sr.No. | Type of Machine | No. of Machine | Size | Make |
|---|---|---|---|---|
| 1 | CNC Turning Center | 01 | 600 x 800 mm | Ace Designer Ltd. |
| 2 | CNC Turning Center | 10 | 300 x 400 mm | Ace Designer Ltd. |
| 3 | VMC | 04 | 600 x 400 mm | Ace Designer Ltd. |
| 4 | Conventional Lathe | 07 | 250 mm | Local |
| 5 | Drilling Machine | 07 | 25.4 mm | Local |
| 6 | Drilling Machine | 03 | 19 MM | Local |
| 7 | Drilling Machine | 02 | 12.5 mm | Local |
We have sister concern forging facilities below:
- Friction belt drop hammers (2 MT)
- Friction Belt drop hammers (1 MT)
- Mechanical Power Press (350 MT)
- Mechanical Power Press (150 MT)
- Billet Shearing Machine (Max 125 MT)
- Die Shop
- Hydraulic & Neumatic Power Press (500 MT) 03 Nos.
- We have Ring Rolling Capacity Range from 40.0 mm dia. to 500.0 mm dia. max. Production Capacity 350 MT/Month
- Ring Rolling Capacity up to 500.0 mm dia. Max.
Our CNC Machining Facilities are Capable of Producing both Milling and Turning Components Ranging in size from 10.0 mm dia. to 600.0 mm dia. max.
Test Facilities
| Name of Test | Facility at our end |
|---|---|
| Chemical Test | Wet Analysis |
| Macrostructure Examination | Acid Etching Kit/DP Test Kit |
| Microstructure Examination | Metallurgical microscope |
| Jominy Test | Jominy test apparatus. |
| Magnaflux Test | Crack detection machine |
| Hardness Test | Brinnel/Rockwell hardness testers |
| Tensile Test | Universal testing machine |
| Impact Test | Impact test equipment |
| Radiography Test | Outsourced as & when required |
| Ultrasonic Test | Outsourced as & when required |
